16.08kWh LiFePO4 BOS-B PRO-A3 HV Battery Module

SKU: 12794 | VT: BOS-B-Pack16-A3
12794-2
12794-3
12794-4
12820

  • Scalable System Configuration: 5–16 Modules in Series
  • System Energy Range: 80.4–257.2 kWh
  • System Voltage Range: 256–819.2 V
Downloads
Manual
|APP|BConfig
IEC 63056
IEC 62619
Technical Specifications
EMC License
LVD License
Specifications
General Information
Electrical Data
Wattage
16.08kWh
Current
Max Charge/Discharge Current 180A
Voltage
51.2Vdc
Body Details
Mount
On a Rack
Capabilities
IP Rating
IP20
Battery Capacity
314Ah
Cells Chemistry
LiFePO4
Working conditions
  • Operating Temperature (Charge): 0 ~ 55°C ;
  • Operating Temperature (Discharge): -20 ~ 55°C
  • Storage Temperature: 0 ~ 35°C ;
On/Off cycles
≥6000 cycles (25±2°C, 0.5C/0.5C, EOL 70%)
Dimensions
Size
526 x 795.9 x 274.2 mm
Product Data
Order code
12794
Product code
BOS-B-Pack16-A3
Items per pack
1
Item Weight
126 kg
Additional
Release Date
25.09.26
Brand
Deye
Warranty
10 years
