2kW On Grid Solar Inverter Single Phase 5 yrs Warranty

SKU: 11956 | VT: SUN-2K-G04P1-EU-AM1
11956-2n
11956-3n
11956-2
11956-3
11956-4

Downloads
Manual
Declaration of Conformity
EN 50549
Technical Specifications
EMC License
LVD License
CEI 0-21
Specifications
General Information
Electrical Data
Wattage
  • Max. PV Input Power: 2.6kW;
  • Rated AC Output Active Power: 2kW
Current
  • Max. Operating PV Input Current: 20A;
  • Max. Input Short Circuit Current: 30A;
Voltage
  • Max. PV Input Voltage: 550V ;
  • MPPT Voltage Range: 70-500V;
  • Rated PV Input Voltage: 360V;
  • Start-Up Voltage: 80V;
  • Rated Output Voltage/Range: 220/230 0.85Un-1.1Un;
Frequency
Rated Output Grid Frequency/Range(Hz): 50/45-55, 60/55-65
Power Factor
0.8 leading to 0.8 lagging
Capabilities
IP Rating
IP65
Working conditions
-25 to +65℃, >45℃ Derating
Dimensions
Size
280 x 310 x 184 (Excluding Connectors and Brackets)
Product Data
Order code
11956
Product code
SUN-2K-G04P1-EU-AM1
Item Weight
6.35 kg
Items per box
1
Additional
Release Date
15.06.2024
Brand
V-TAC
Warranty
5 years
